Yale MRW020-30E

Pallet Stackers


Need Assistance?

Let us help you find what you need.

Productivity and Superior Quality in Warehousing Applications


Durability and reliability are the pillars of Yale® lift trucks used in manufacturing applications. The MRW020-30E trucks extend your time on the warehouse floor with features that enhance productivity, including the separately exited drive motor and transistorized hoist and traction controller.

Operators prefer Yale® lift trucks for their innovative design that reduces fatigue and optimizes performance. Ergonomic factors such as the convenient on-board diagnostic and large control handle promote productivity and efficiency. Designed to require less maintenance, the MRW020-30E truck is easy to service and includes fill and drain plugs to insure adequate lubrication.

Productivity and Superior Quality in Warehousing Applications


Durability and reliability are the pillars of Yale® lift trucks used in manufacturing applications. The MRW020-30E trucks extend your time on the warehouse floor with features that enhance productivity, including the separately exited drive motor and transistorized hoist and traction controller.

Operators prefer Yale® lift trucks for their innovative design that reduces fatigue and optimizes performance. Ergonomic factors such as the convenient on-board diagnostic and large control handle promote productivity and efficiency. Designed to require less maintenance, the MRW020-30E truck is easy to service and includes fill and drain plugs to insure adequate lubrication.

Features
Specifications
Copy Set

Features

The MRW020-030E bottom mounted tiller handle design optimizes the operating position and reduces the steering effort.

The MRW020-030E excels in manufacturing and warehousing applications where space utilization is a consideration and load widths vary.

The MRW020-030E has been designed using a stationary separately ignited drive motor in conjunction with an advanced transistorized hoist and traction controller to enhance truck performance and reliability.

Three performance modes, easily changed by the operator through the control handle, allow you to tailor truck performance to the application.

Specifications

Capacity:
2,000 - 3,000 lbs
Max Height:
179
Max Weight:
3000 lbs
Series Title:
MRW020-30E
Type:
Powered Pallet Reach Stacker
Weight:
lbs

ModelTable

Model Model Designation Load Capacity (lbs.) Battery Maximum Travel Speed (mph) Maximum Lift Speed (ft/min) Lower Lift Speed (ft/min)
MRW030-E Pallet Stackers 3000  24 3.5 30 43
MRW020-E Pallet Stackers 2000  24 3.5 30 43
