Yale NTA030/035SB

Very Narrow Aisle


Need Assistance?

Let us help you find what you need.

Productive Forklifts for Narrow Warehousing Solutions


The NTA series is ideal for pallet handling and case picking, making it the perfect truck for warehousing. The AC power motor in either 48 or 72-volts offers fast speeds, powerful acceleration and outstanding precision that increases the number of loads per shift.

It has been proven that operators prefer Yale® trucks for their innovative ergonomic technologies, such as the infinity variable armrests, high backrest and recessed swivel seat, all of which reduce fatigue and improve productivity.  The NTA030SB and NTA035SB trucks are also designed to require less service, reducing maintenance costs and improving uptime.

Productive Forklifts for Narrow Warehousing Solutions


The NTA series is ideal for pallet handling and case picking, making it the perfect truck for warehousing. The AC power motor in either 48 or 72-volts offers fast speeds, powerful acceleration and outstanding precision that increases the number of loads per shift.

It has been proven that operators prefer Yale® trucks for their innovative ergonomic technologies, such as the infinity variable armrests, high backrest and recessed swivel seat, all of which reduce fatigue and improve productivity.  The NTA030SB and NTA035SB trucks are also designed to require less service, reducing maintenance costs and improving uptime.

Features
Specifications
Copy Set

Features

The NTA series of man up turret trucks are the new standard in high density warehousing, offering top performance, ergonomics and economic value.

The NTA man up design allows productive load handling, regardless of lift height.

While the NTA series requires less maintenance, it’s extremely serviceable for such occasions.

Advanced technology, superior ergonomic design, application flexibility and Yale quality all add up to increased productivity and reliability.

Specifications

Capacity:
3,000 – 3,500 lbs
Max Height:
668
Max Weight:
3500 lbs
Series Title:
NTA030/035SB
Type:
Very Narrow Aisle Forklift Turret Trucks
Weight:
lbs

ModelTable

Model Model Designation Load Capacity (lbs.) Battery Maximum Travel Speed (mph) Maximum Lift Speed (ft/min) Lower Lift Speed (ft/min)
NTA030SB Very Narrow Aisle 3000 48 6.5 83 98
NTA035SB Very Narrow Aisle 3500  72 6.5 79 118
