Yale GC080-120VX

IC Cushion Tire


Need Assistance?

Let us help you find what you need.

Customizable Lift Trucks That Get the Job Done


The Veracitor® GC080-120VX lift truck series delivers maximum performance for medium to heavy duty indoor applications. By supplying various powertrain combinations, the series offers the flexibility to meet your application needs, while also providing standard features and options to maximize the productivity, efficiency and performance of your operations.

Customizable Lift Trucks That Get the Job Done


The Veracitor® GC080-120VX lift truck series delivers maximum performance for medium to heavy duty indoor applications. By supplying various powertrain combinations, the series offers the flexibility to meet your application needs, while also providing standard features and options to maximize the productivity, efficiency and performance of your operations.
Features
Specifications
Copy Set

Features

Engine features Yale® Flex Performance Technology™, selectable performance modes that provide the flexibility to maximize fuel economy or productivity to match application requirements

Powertrain combinations include Kubota 3.8L spark-ignited LPG engine

Full venting package draws air into the engine compartment from higher on the truck to enhance airflow and avoid radiator clogging

Fully sealed wet disc brakes virtually eliminate brake maintenance and often last the life of the truck

Advanced transmissions are built for durability and patented controllability, while extending tire and brake life up to 50%

Combi-cooler contains an individual transmission oil cooler to maximize heat dissipation

On-demand hydraulic system featuring Accutouch mini-lever controls pumps oil only when required, reducing fuel consumption

For applications requiring the use of attachments; Yale® attachment ready models are available with a factory modified front end, which allow for seamless truck and Bolzoni Auramo attachment interface.

Ergonomic operator compartment includes optimized step height with non-slip tread, soft touch contoured hand grip and infinitely adjustable steer column

Specifications

Capacity:
8,000 - 12,000 lbs
Max Height:
310
Max Weight:
12000 lbs
Series Title:
GC080-120VX
Type:
Internal Combustion Cushion Tire Lift Truck
Weight:
lbs

ModelTable

Model Model Designation Load Capacity (lbs.) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
GC080VX Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 14 122
GC080VXBCS Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.9 122
GC100VX Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.8 112
GC100VXBCS Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VX Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VXPRS Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
